G34301149230

Description

Carlo Gavazzi G34301149230 Dupline 16-Channel Relay Output Module: High-Density Control for Industrial Automation

In distributed control systems requiring multiple output signals, the Carlo Gavazzi Dupline Module G34301149230 provides a robust and space-efficient solution. As a 16-channel relay output module designed for the Dupline fieldbus system, it delivers high-density switching capability for various industrial loads while maintaining the proven reliability and long-distance communication strengths of the Dupline platform.

Product Overview and Technical Specifications

The Carlo Gavazzi G34301149230 serves as a slave device on the Dupline network, enabling centralized control of up to 16 independent loads through a single bus connection. Its modular design integrates multiple electromechanical relays in a compact housing, significantly reducing installation space compared to individual relays or smaller modules.

Key Features:

• 16-Channel Configuration: Provides 16 Form A (SPST-NO) or Form C (SPDT) relay outputs (specific configuration verified in datasheet)

• Contact Rating: Typically 2A @ 250V AC/30V DC per channel, suitable for motors, solenoids, and lighting

• Dupline Compatibility: Fully integrated with Dupline fieldbus systems using standard two-wire connection

• LED Indicators: Individual channel status LEDs for visual output confirmation

• Isolation: Galvanic isolation between field outputs and control bus

• Mounting: Standard DIN-rail installation for control panel integration

Application Scenarios

Industrial Automation: The module excels in manufacturing environments controlling multiple actuators, conveyor sections, and processing equipment. Its high channel density makes it ideal for packaging machinery, assembly lines, and material handling systems where space optimization is crucial.

Building Management: In HVAC and facility control applications, the G34301149230 efficiently manages ventilation dampers, pump controls, and lighting circuits across distributed building areas using Dupline’s long-distance capability.

Technical Advantages

The module’s design emphasizes operational reliability with built-in protection against voltage transients and electrical noise. Each relay channel includes arc suppression for inductive loads, while the collective design ensures heat dissipation doesn’t compromise performance. The Dupline integration enables real-time status monitoring and control from a central location, even across distances up to 10 km.

Installation and Configuration

Address assignment via DIP switches establishes the module’s position on the Dupline network. The wiring design incorporates high-density terminal blocks that maintain accessibility while accommodating multiple field connections. Maintenance is streamlined through the immediate visual feedback provided by channel status indicators.

Conclusion

The Carlo Gavazzi G34301149230 represents an optimal balance between channel density and switching capacity for industrial control applications. By incorporating 16 relay outputs in a single Dupline-compatible unit, it reduces hardware complexity while maintaining the reliability expected from Carlo Gavazzi automation components. For system integrators designing distributed control architectures requiring multiple output points, this module delivers both space efficiency and operational reliability.

---
